CS TopMountTrack - Single

The CS TopMountTrack™ - Single is a sleek, low-profile track system designed for smooth operation and versatility. It's a popular choice for various openings, including pocket, barn, partition, and multi-sliding doors.

The clip-on fascia is perfect for barn door and partition applications. The CS TopMountTrack - Single can be upgraded with the SofStop® soft-close feature, making it ideal for quiet environments like bedrooms, offices, and patient rooms.

Product Specifications

CaviTrack Top Mount Track Single Combined Specification Drawing

Features

CS TopMountTrack™ - Single

Suitable for incorporating into pocket frame assemblies for a smooth running high end system.
Tracks can be configured to suit Bi-Parting door set-ups, including CornerMeeting detail.
Clip-on fascia allows the TopMountTrack to be mounted from the side for a barn door configuration. Standard finishes: Clear or Bronze Anodized. Inquire about custom colors.
Pre-machined mounting holes.

Soft Close Option: Can be upgraded to SofStop® soft close for quiet operation.

Side Mount Option: All TopMountTracks are available with fascia to shroud the exposed track in a side-mounted configuration for a pleasing aesthetic.

Application Areas: Suitable for bedrooms, closets, offices, patient rooms, restrooms, hallways, laundries, and architectural feature openings.

Technical Details

Track Finish: Milled Aluminum

Fascia Finish: Clear or Bronze Anodized Aluminum

Maximum Door Thickness: No limit when specified without fascia, With fascia: 35-45mm (1-3/8” - 1-3/4”)

Maximum Door Weight: 500 lb (240 kg), With SofStop: 350 lb (158 kg)

Maximum Track Length: 24’ (7.3m)

Track Height: 1-5/8” (42mm)

Carriages: M6 (200lb), M8 (500lb), SofStop, SofStop HD

How to Specify

Step 1. Determine Door Width: Generally, your track length should be twice your door width.

Step 2. Select Track Length: Multiply your door width by two. Choose from pre-cut lengths: 6', 8', 12', 24'. Tracks can be cut down for custom widths.

Step 3. Select Carriage Pack: Choose one pack per door. Each pack includes carriages, mounting plates, T-Guide, screws, and an adjusting wrench.
For standard operation, select M6 (200lb/90kg) or M8 (500lb/240kg). For soft close, consult our SofStop Minimum Door Width table.

A Track Stop is needed when no physical stops are present, i.e., your door does not come to rest at a closing jamb or wall stud. If this is the case for your installation, be sure to choose a carriage pack that includes a stop.

Step 4 Fascia and End Caps (Optional): For partition and side mount applications, clip-on fascia and end caps are available in natural or bronze anodized finishes. Custom finishes are available for commercial projects.
