Features
Maximum Size - Door sizes up to 3500mm High x 4500mm Wide & up to 88mm Thick
Wall Framing -140mm - no packing of the frame is required
Maximum door weight - 240kg
SofStop: 100kg Single and 50kg Twin SofClose
How to Specify (example)
Product: ~ CS Ultimate Cavity Slider
Location: ~ Room divider
Door leaf dimensions: ~ 3000mm x 1200mm
Door type: ~ 55mm joinery door
Door finish: ~ Paint Quality
Single or Bi-Parting: ~ Single
Operation: ~ SofStop 100kg
Jamb type & finish: ~ Pine flat (for architraves)
Framing material & size: ~ 140mm timber framing
Wall lining thickness: ~ 10mm
Handle type: ~ CaviLock CL100 Lever
