Full-Height Track

The CS Full Height ceiling mounted track allows the ceiling lining to be fixed flush with the underside of the track, ensuring a seamless continuation of the ceiling line where the door slides. The track can also be painted on-site to match the ceiling colour, blending perfectly with your interior design.

Product Specifications

Explore Our Range

Product Specifications

FH-CeilingMountTrack Spec Drawing Compilation

Features

Maximum Track Length - 10m
Maximum Door Thickness - 40mm (when using multiple tracks)
Maximum door weight: 240kg (standard), 100kg (SofStop)
Track is high quality, heavy duty extruded aluminium.
Tracks may be anodised where required or painted to blend in with ceiling finishes.
1, 2, 3, 4 or 5 track set-ups available.
Fits into typical ceiling batten spaces - total track height is 36mm.
Door pick-up system is available where multiple doors are used.
Carriages: M6 (120kg), M8 (240kg), Compatible with the CS SofStop (Single or Twin)

How to Specify (Example)

Product:~ CS Full-Height Track
Location:~ Boardroom
Track Configuration:~ Double Track
Track Length:~ 6 metres
Number of doors:~ 2
Door Configuration:~ Overtaking
Carriage Pack:~ M8 240kg with Pickup pack for Overtaking doors

Pack Components

Track - cut to specified length
Single, Bi-Parting or SofStop wheel pack
All required T-Guides and track stops
Track fixing screw sets

Options

The CS Full Height-CeilingMountTrack has a wide variety of configurations, wall finishing options and additional features in the Detail Options.

Detail Options

Incorporate any of the following architectural detail options with the CS Full-Height Track to create a specific look or to provide a unique solution:
