Options
Right and Left Handing
Features
- Compliant with ADA Standards for Accessible Design
- Easy to use - no tight pinching or twisting of the wrist
- Matches other hardware in the CL100 range
- Egress Free - Even when in locked position the handle on the inside remains unlocked
Finishes
Brushed Stainless Steel
Minimum Door Thickness
1-3/8" (34mm)
Backset
2-3/64” (56mm)
Suitable Door Types
Wooden, Aluminum, steel
Finishes
Satin Chrome, Polished Brass
ADA Compliance
Operable parts of hardware must be mounted 34” (865mm) min. and 48” (1220 mm) max. above the finished floor to meet ADA guidelines.
The clear width of the door opening must be a minimum of 32”. Always check State and Federal guidelines relating to the specific project.
