How to Specify
Step 1. Determine Door Width: Generally, your track length should be twice your door width.
Step 2. Select Track Length: Multiply your door width by two. Choose from pre-cut lengths: 6', 7', 8', 9', 10', 13', 14', 15', 16', 17', 18' and 19’. Tracks can be cut down for custom widths.
Step 3. Determine Overall Thickness: This track system is available with either a Narrow or Wide track bracket, which must be specified when placing your order. The bracket can be adjusted to suit an overall thickness of door + gap + moulding of:
1-5/8” to 2-3/8” (40 - 61mm) (Narrow option) or
2-3/8” to 3-1/8” (62 - 80mm) (Wide option).
Step 3. Select Hanger Pack: Choose one pack per door. Each pack includes carriages, mounting plates, T-Guide, screws, and an adjusting wrench.
For standard operation, select standard CS Barn Door Hangers & Stops Pack.
For SofStop, select two SofStop Single Packs. The SofStop system supports a maximum door weight of 264 lbs and requires a minimum door width of 24 inches.
