Features
TopMountTrack - Single: Suitable for incorporating into pocket frame assemblies for a smooth running high end system.
TopMountTrack - Double/Triple: Tracks can be used for bypass and collection systems.
- Tracks can be configured to suit Bi-Parting door set-ups, including CornerMeeting detail.
- Clip-on fascia allows the TopMountTrack to be mounted from the side for a barn door configuration. Standard finishes: Clear or Bronze Anodized. Inquire about custom colors.
- Pre-machined mounting holes.
Soft Close Option: Can be upgraded to SofStop® soft close for quiet operation.
Side Mount Option: All TopMountTracks are available with fascia to shroud the exposed track in a side-mounted configuration for a pleasing aesthetic.
Door Collection System: Where multiple doors are required to slide in conjunction with one another, the CS Door Collection System ensures a smooth running telescopic system. The doors are connected so that there is no need for floor tracks or guides through the opening.
Application Areas: Suitable for bedrooms, closets, offices, patient rooms, restrooms, hallways, laundries, and architectural feature openings.
Technical Details
Door Thickness: 1-3/8” or 1-3/4” (35 or 45mm) or no limit when supplied without fascia for TopMountTrack - Single
Maximum Door Weight: 500lb (240kg), With SofStop: 350 lb (158kg)
Maximum Track Length: 24’ (7.3m)
Track Height: 1-1/2” (36.5mm)
Carriages: M6 (200lb), M8 (500lb), SofStop, SofStop HD
Configurations: Single Track, Double Track Bypass or Collection System, Triple Track Bypass or Collection System
