CS SoundStop

Introducing the CS SoundStop Cavity Slider, combining all the features of our standard models with advanced acoustic ratings up to STC42/RW 42 dB. Perfect for projects requiring superior sound control, these units come complete with a specialised acoustic door panel. Equipped with brush seals at the bottom and a seal bar at the back edge, our units are fully accredited and tested by Acoustics Testing Services. Designed to fit standard thickness stud walls, the SoundStop Cavity Slider is supplied as a complete unit with factory-fitted doors and seals, ensuring no visible guides in the opening or on the door. Enhance your space with this high-performance, aesthetically pleasing acoustic solution.

Product Specifications

Features

Maximum Size - Timber = Door sizes up to 2080mm High x 860mm Wide; AluTec Door = 2500mm High x 2200mm Wide
* Large SoundStop timber doors may be manufactured in two pieces with a specialised joining system, creating a negative detail on both sides of the door

Wall Framing - 90mm

Maximum door weight - 240kg

Wall Linings - Minimum 13mm

Acoustic Rating - SoundStop Timber door = STC42/RW 42 dB; AluTec Door = STC 36/RW36 dB

How to Specify (example)

Product: ~ CS SoundStop by CS Cavity Sliders

Location: ~ Media Room

Door leaf dimensions: ~ 2200mm x 1600mm

Door type & finish: ~ CS AluTec

Single or Bi-Parting: ~ Single

Jamb type & finish: ~ Pine Flat for architraves

Framing size & material: ~ 90mm timber framing

Wall lining thickness: ~ 13mm (minimum)

Handle type: ~ CaviLock CL400 Privacy

Acoustic Rating: ~ STC 36/RW36 dB

Alutec SoundStop Door

The AluTec is also available for use with the SoundStop cavity slider for a sound rated solution. It has been tested to STC 36 and is suitable for single doors up to 2400 x 2200mm. GIB® Noiseline® 13mm linings must be used.
