The TimberFormed cavity slider is engineered for ultimate adaptability, accommodating made-to-measure sizes up to 3000mm high x 3500mm wide. With an impressive door weight capacity of 240kg, this cavity slider is perfect for even the most demanding applications. The TimberFormed cavity slider offers a robust and efficient solution for maximising space in any environment. Enhance your space with this durable and customisable sliding door system that integrates seamlessly with your design.

Product Specifications

CavitySliders - TimberFormed Spec DrawingCavitySliders - TimberFormed Spec Drawing

Features

Maximum Size - Door sizes up to 3500mm High x 3500mm Wide & up to 40mm Thick

Wall Framing - 90mm

Maximum door weight - 240kg

SofStop: 50kg & 100kg Single and 50kg Twin (Soft Open/Close)

How to Specify (example)

Product: ~ CS TimberFormed Cavity Slider

Location: ~ Lounge/Dining

Door leaf dimensions: ~ 2400mm x 1200mm

Door type: ~ 38mm door

Door finish: ~ Paint Quality

Single or Bi-Parting: ~ Single

Operation: ~ SofStop 100kg

Jamb type & finish: ~ Pine flat (for architraves)

Framing material & size: ~ 90mm timber framing

Wall lining thickness: ~ 13mm

Handle type: ~ CaviLock CL400 Passage

Detail Options

Incorporate any of the following architectural detail options with CS TimberFormed to create a specific look or to provide a unique solution:
