ShadowLine

ShadowLine detail, also known as Negative detail, adds a modern touch to door jamb liners. This popular design feature is made simple with a ShadowLine unit.

Product Specifications

ShadowLine-detail NZShadowLine-detail NZ

Features

Contemporary Design: Timber jambs are designed with a 10 x 10mm rebate around the liners to assist builders in achieving this sleek look. You can choose from Architrave, Grooved or AluSealed Jambs. The ShadowLine detail is available with most CaviSliders and CaviRobes.

Timber Jamb Option: If timber jambs are used, the jamb can be supplied with a non-standard return. Wall linings are run up to within 10-13mm of this return to create a negative detail. If required, a ‘Z’ mould can be used.

Aluminium Jamb Option: If aluminium jambs are used then two layers of plasterboard are required to create the detail. The first acts as a packer (13mm) and the second creates the detail. The jambs are supplied with a reduced face width so that the overall jamb width matches the finished wall thickness.

Installation Tips

In all cases standard Installation Instructions will apply. The wall lining installation is the major contributor to this detail. Extreme care must be taken when fixing linings, as clean square edges of the lining are critical to create an accurate ShadowLine detail.
