CS HeavyDutyTrack

CS HeavyDutyTrack

Specifications
Downloads

The CS HeavyDutyTrack is a robust sliding door track system engineered to accommodate oversized or heavy doors weighing up to 1100lb (500kg).

Designed for versatility, it serves a variety of commercial, industrial, and residential applications.

Product Specifications

HeavyDutyTrack Specification DrawingHeavyDutyTrack Specification Drawing

Features

  • High-quality, ultra heavy-duty extruded aluminum track designed to take oversized or heavy doors up to 1100 lb.
  • Pre-machined mounting holes
  • Includes our M10 Carriage Packs made from cast stainless steel and extra-large diameter nylon wheels with precision ground bearings for strength, reliability, and smoothness.

Applications: Oversized pocket doors, extra-large barn doors, featured openings, factory doors, openings with doors heavier than 500 lb, and any project that calls for oversized and heavy sliding doors. Suitable for a wide range of commercial, industrial, and residential projects.

Technical Details

Track Finish: Clear Anodized Aluminum

Minimum Door Thickness: 1-9/16” (40mm)

Maximum Door Weight: 1100 lb (500kg)

Maximum Track Length: 28’ (8.5m)

Track Height: 2-3/16” (56mm)

Track Width: 3-1/16"” (77.5mm)

Carriage Pack: M10 (1100 lb)

How to Specify

Step 1. Determine Door Width: Generally, your track length should be twice your door width.

Step 2. Select Track Length: Multiply your door width by two. Tracks are available in lengths up to 24'.

Step 3. Select Carriage Pack: Order an M10 (1100lb/500kg) carriage pack per door. Each pack includes carriages, mounting plates, T-Guide, screws, and an adjusting wrench.

A Track Stop is needed when no physical stops are present, i.e., your door does not come to rest at a closing jamb or wall stud. If this is the case for your installation, be sure to choose a carriage pack that includes a stop.

Videos

Laurie McCowan and Bruce Hodgson with MG Partners took us to this beautiful home in Bel Air, California, where stunning floor-to-ceiling stone pocket doors were installed using the CS HeavyDutyTrack. With some doors weighing over 1000 lbs, the team at MG Partners chose the CS HeavyDutyTrack to ensure these doors glide smoothly and reliably. The CS HeavyDutyTrack can support massive projects and take your designs to the next level, all while maintaining the quality and reliability that CS Cavity Sliders is known for. 00:00 Introduction 00:43 Who are MG Partners? 01:22 1400 lb. Giant Stone Pocket Doors 01:58 Utilizing the CS Heavy Duty Track System 2:13 10' Tall Doors 2:34 MG Partners' attention to detail 2:53 Outro Learn more about the CS HeavyDutyTrack: https://www.cavitysliders.com/Contact?utm_source=youtube&utm_medium=organic_social&utm_campaign=Oct15_071423+-+Brentwood Email: info@cavitysliders.com Phone: (888) 466 0030 Website: https://www.cavitysliders.com/ Linkedin: https://www.linkedin.com/company/cavitysliders Instagram: https://www.instagram.com/cavitysliders/ Facebook: https://www.facebook.com/CavitySlidersUSA Pinterest: https://www.pinterest.com/cavitysliders/

Laurie McCowan and Omar Leon with OLCustomCarpentry took us to this beautiful home in Bel Air, California. Inside, this extra-large telescoping pocket door system was skillfully installed using the CS HeavyDutyTrack and customized CS Collection System. With each door weighing over 500 lbs., Omar and his team chose the CS HeavyDutyTrack and CS Collection system to ensure these doors operate smoothly and reliably. The CS HeavyDutyTrack and CS Collection system can support grand projects like this and take your designs to the next level, all while maintaining the quality and reliability that CS Cavity Sliders is known for. 00:00 Introduction 00:24 Size of the Doors 00:41 Cavity Sliders Products Used: CS HeavyDutyTrack and CS Collection System 00:53 Checking out the Door's Installation 01:18 Admiring the Finishing Details: Door Trim and Clearances 02:00 Outro Follow @OlCustomCarpentry on Instagram: https://www.instagram.com/olcustomcarpentry/ Learn more about the CS HeavyDutyTrack: https://www.cavitysliders.com/products/track-systems/heavydutytrack?utm_source=youtube&utm_medium=organic_social&utm_campaign=Dec2_092023+-+OLCustomCarpentry+Bel+Air+Los+Angeles+Door+Collection+System Learn more about the CS Collection System: https://www.cavitysliders.com/products/track-systems/door-collection-system?utm_source=youtube&utm_medium=organic_social&utm_campaign=Dec2_092023+-+OLCustomCarpentry+Bel+Air+Los+Angeles+Door+Collection+System Email: info@cavitysliders.com Phone: (888) 466 0030 Website: https://www.cavitysliders.com/ Linkedin: https://www.linkedin.com/company/cavitysliders Instagram: https://www.instagram.com/cavitysliders/ Facebook: https://www.facebook.com/CavitySlidersUSA Pinterest: https://www.pinterest.com/cavitysliders/
